WINDMASTER® DC SERIES

WINDMASTER® DC SERIES - the industry leader with slant housing for efficiency and easy mounting.

Available sizes: 24" - 30" - 36" - 42" - 48" - 54"

WINDMASTER® DC SERIES – The industry leader.

• Six-bladed propeller utilizing a cambered-twist blade designed with a unique dihedral tip for higher air flow capacities at less horsepower.
• Non-overloading design maintains horsepower within catalog range of static pressure, resulting in lower motor load and reduced operating costs.
• Streamlined orifice insures higher air flow capacity
• Available mounted in slant housing, slant housing and diffuser or square wall housing.
• Rust protected with a metal wash process and a baked on finish.
• Slant housing provides better efficiency along with ease of installation
• Spring belt tightener makes sure the fan is always running with peak efficiency.
• 2 year comprehensive warranty, 5 year shaft and bearing assembly warranty.

OPTIONS FOR BDR & DC:

Fan only

Fan with slant housing

Fan with cone
